Product Spotlight

Mini Circuit Breakers

Discover the best in circuit protection

Designed for optimum protection against overload and short circuits, IMO’s range of Mini Circuit Breakers (MCBs) help bridge the gap in electrical installations.  IMO MCBs are available in 1P, 1P+N, 2P, 3P and 3P+N, with current range from 1A to 63A. These MCBs also ensure breaker tripping safety with 10kA short circuit breaking capacity.

All IMO MCBs are RoHS 2 compliant and a number carry the following approvals: CE; VDE; Kema Keur; GOST; RCM. Available accessories include: auxiliary switches, Shunt Trip, busbars and locking devices.

Key Features

  • Handle central-tripping function for circuit fault indicating
  • High short circuit capacity
  • Applicable to terminal and pin/Fork type busbar connection
  • Handle padlock device
  • Finger protected connection terminals

Specifications

Rated voltage: 230V/400V AC, Max. 60VDC

Rated insulation voltage Ui: 500V

In accordance with: EN60898, EN60947-2, UNE20317

Terminal capacity: 1 to 25mm2 up to 25A
25 to 35mm2 up to 63A

Breaking capacity as per IEC60898: 6kA B curve 1 pole,
10kA C & D curve 1-3 poles

Breaking capacity applying IEC60947-2: up to 15kA

Mounting: on Rail EN60715 (EN50022)

Protection degree: IP20
